Delta DVP16SP-R PLC Extension

📖 Description

• The DVP16SP-R is a digital output expansion module from Delta’s DVP series, designed to extend the output capacity of Delta PLC systems. It offers 16 relay-type digital outputs, ideal for controlling external devices such as solenoids, relays, and indicators. With its compact size and DIN-rail mount compatibility, it is perfect for industrial automation tasks that require reliable output switching.

🔧 Technical Specifications

• Model: DVP16SP11R (Delta DVP-S Slim Series)

• Power Supply: 24 V DC (20.4–28.8 V, polarity protected)

• I/O Configuration: 8 digital inputs + 8 relay outputs

• Input Type: Sink or Source selectable (24 V DC)

• Output Type: SPDT relays, 1.5 A per point, 5 A common contact; rated 250 VAC / 30 V DC

• Current Consumption: Max ~2 W

• Mounting: Clips onto right-side of DVP-S series PLC, shares bus and power

• Dimensions & Weight: Approx. 90 × 60 × 25 mm; ~0.16–0.35 kg

• Operating Temp: 0–55 °C, ≤95 % RH

• Certifications: RoHS; ESD immunity to 8 kV air, 1 kV signal lines

⚙️ Features

• Slim DIN-rail design that attaches directly to DVP-S PLC units without extra wiring

• LED indicators on inputs and outputs for easy status confirmation

• Configurable input mode (NPN or PNP) to match sensor logic requirements

• Relay outputs enable switching of AC and DC loads, ideal for actuators and external devices

• Bus-powered for a tidy installation—no external wiring between PLC and module

🛠️ Applications

• PLC I/O Expansion: Increase your DVP-S series PLC’s I/O capacity without additional wiring

• Industrial Control Tasks: Use relay outputs to drive contactors, solenoids, valves, alarms, etc.

• Automation Systems: Relays are ideal for tasks like motor control, pump switching, and conveyor interfacing

• Flexible Input Wiring: Sink/source selection ensures compatibility with a wide range of sensors

• Plant Environments: Compact size and DIN-rail mounting suit factory, HVAC, packaging, and processing systems
