Toggle Switch DPST – ON-OFF, 250V 15A with cup waterproof

📖Description:

• A compact and reliable limit switch equipped with a roller lever actuator for precise mechanical positioning. Suitable for industrial automation, conveyors, machinery safety systems, and mechanical controls.

🔧 Key Specifications

• Switch Type: DPST (Double Pole Single Throw)

• Operation: ON-OFF (maintained, not momentary)

• Pins: 4 screw terminals

• Rated Voltage: 250V AC

• Rated Current: 15A

• Mounting Hole Diameter: 12 mm

• Contact Resistance: ≤ 20 mΩ

• Insulation Resistance: ≥ 100 MΩ at 500V DC

• Dielectric Strength: 1000V AC for 1 minute

• Dimensions: Approximately 30 x 19 mm panel cutout
